C ON -X M OLDED C ABLE A SSEMBLY C HECK L IST
Company Name:
Address:
Customer Name:
City
Phone:
Website:
Annual Usage Quantity:
Does the assembly need to be RoHS compliant?
Cable Vendor and Part Number (if available):
State:
Fax:
E-mail:
Monthly Usage Quantity:
Yes:
Zip:
No:
Cable Outer Jacket - Color:
Number of Conductors:
Conductor Colors:
Is there a drain wire?
Material:
Conductor AWG:
Is the drain wire terminated?
OD:
Stranding:
*If the drain wire is terminated, be sure to indicate where on pin-out diagram.
Is the cable shielded?
How? Foil
Braid
%
*If the shield is braided, be sure to indicate where on the pin-out diagram.
Will the Customer supply the cable for production?
Cable Cut Length:
Overall Assembly Length:
Does the Cable Assembly have Environmental Requirements?
If yes, please list them:
Must overmold have a moisture bond to the cable’s outer jacket?
Is the Cable Assembly:
Single ended:
Double Ended:
Do the connectors need to be shielded?
If yes, do they need to be: 180o shield:
End “A” Connector Part Number:
End “B”, will that end need processing?
OR Shield thru pin:
Right Angle?
If yes, indicate below:
Outer jacket strip length:
Inner Conductor strip length:
Tinned?
Does end “B” have any special inclusions? If yes, please list them:
Note: Please submit a diagram of the color code pin-out, showing which conductors are wired to which
pin position. Be sure to show drain and shield terminations, if needed. Indicate empty pins or spaces to
be molded closed where required. If a drawing assembly is available, please send it also.
?
